Type M18 for factory automation
The threaded design most commonly used for laser sensors in automation technology is the type OG with M18 housing. The robust stainless steel housing enables the reliable detection of even the smallest objects in rugged industrial environments. The units are distinguished by long ranges, long-term stability and high switching frequencies. Diffuse reflection sensors ensure very precise background suppression, thus preventing unintentional switching also in demanding applications.
The product range includes through-beam sensors, retro-reflective sensors and diffuse reflection sensors. On laser sensors with teach mode, ranges, light-on and dark-on mode and, in the case of diffuse reflection sensors, background suppression, can be set conveniently via pushbuttons.
- Reliable detection of tiny objects
- Excellent price/performance ratio
- Visible red light for simple alignment
- Setting process saves time and cost during set-up
- Precise background suppression
| MPN | Product designation | Dimensions | Range | Range referred to prismatic reflector | Material |
|---|---|---|---|---|---|
| OGE700 | Through-beam sensor | M18 x 1 / L = 72 mm | < 60 m | stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU (urethane) | |
| OGE701 | Through-beam sensor | M18 x 1 / L = 72 mm | < 2 m | stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU (urethane) | |
| OGH700 | Diffuse reflection sensor | M18 x 1 / L = 72 mm | 20...200 mm | stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU (urethane) | |
| OGH701 | Diffuse reflection sensor | M18 x 1 / L = 72 mm | 20...200 mm | stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU (urethane) | |
| OGP700 | Retro-reflective sensor | M18 x 1 / L = 72 mm | 0.2...15 | housing: stainless steel (1.4404 / 316L); operator interface: PA; sealing: EPDM; Pushbuttons: TPU (urethane) | |
| OGP701 | Retro-reflective sensor | M18 x 1 / L = 72 mm | 0.2...2 | housing: stainless steel (1.4404 / 316L); operator interface: PA; sealing: EPDM; Pushbuttons: TPU (urethane) | |
| OGS700 | Through-beam sensor | M18 x 1 / L = 72 mm | < 60 m | stainless steel (1.4404 / 316L); PA; EPDM | |
| OGS701 | Through-beam sensor | M18 x 1 / L = 72 mm | < 2 m | stainless steel (1.4404 / 316L); PA; EPDM |
