Headline
Assembly and fine adjustment units
The angle of radiation of laser units is small. The fixture for fine adjustment allows easy alignment of the laser beam to a laser receiver or triple reflector. In addition, this mounting system provides increased vibration resistance.
Features & Benefits
- User-friendly alignment of the laser beam to a laser receiver or prismatic reflector
- High vibration resistance
Additional Notes
| MPN | Product designation | Design | Material | Type of mounting |
|---|---|---|---|---|
| E1D100 | Mounting and fine adjustment bracket for laser units | Clamp mounting | fixture: aluminum transparent anodized; plastics: POM; screws: stainless steel | rod or free-standing depending on the clamp |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-110060010 | ifm Accessories - for distance sensors - Reflectors | $0.01 | |
| IFM-110060020 | ifm Accessories - for distance sensors - Mounting sets for type O1 | $0.01 | |
| IFM-110060030 | ifm Accessories - for distance sensors - Mounting sets for type O5 | $0.01 | |
| IFM-110060040 | ifm Accessories - for distance sensors - Mounting sets for type M18 | $0.01 | |
| IFM-110060050 | ifm Accessories - for distance sensors - Mounting sets for type M30 | $0.01 | |
| IFM-110060060 | ifm Accessories - for distance sensors - Mounting sets for reflectors | $0.01 | |
| IFM-110060070 | ifm Accessories - for distance sensors - Clamps | $0.01 | |
| IFM-110060080 | ifm Accessories - for distance sensors - Mounting rods | $0.01 | |
| IFM-110060090 | ifm Accessories - for distance sensors - Thread cubes for aluminum profile mounting | $0.01 | |
| IFM-110060100 | ifm Accessories - for distance sensors - Device protection | $0.01 | |
| IFM-110060110 | ifm Accessories - for distance sensors - Cooling boxes and protective housings for distance sensors | $0.01 |
