Headline
Female cordsets
Female cordsets are generally used in automation technology to connect sensors and actuators with connectors to splitter boxes. Even when fastened by hand, a perfect lasting seal of sensor and actuator connections is guaranteed. The integrated end stop protects the O-ring against destruction caused by over-tightening the nut. Even in harsh industrial environments, the connectors are protected against unintended loosening by a special vibration protection. Some types are fitted with highly visible LEDs for operation and switching status indication. ifm's ecolink EVC series sockets are resistant to oils and lubricants, making them ideal for use in machine tools and the metalworking industry.
Features & Benefits
- Reliable sealing even when mounted without tools
- Mechanical end stop to protect the O-ring from destruction
- Sawtooth design protects against shock and vibration
- LEDs clearly visible even under bright lighting
- High material resistance to oils and lubricants
Additional Notes
| MPN | Product designation | Connection | Cable structure | Display | Number of cores |
|---|---|---|---|---|---|
| E12543 | Female cordset | 1 m PUR-Cable; DEUTSCH connector Connector | 3 x 0,50 mm² (28 x Ø 0,15 mm) | 3 | |
| E12544 | Female cordset | 2 m PUR-Cable; DEUTSCH connector Connector | 3 x 0,50 mm² (28 x Ø 0,15 mm) | 3 | |
| E12545 | Female cordset | 5 m PUR-Cable; DEUTSCH connector Connector | 3 x 0,50 mm² (28 x Ø 0,15 mm) | 3 | |
| E12549 | Female cordset | 1 m PUR-Cable; DEUTSCH connector Connector | 2 x 0,50 mm² (28 x Ø 0,15 mm) | 2 | |
| E12550 | Female cordset | 2 m PUR-Cable; DEUTSCH connector Connector | 2 x 0,50 mm² (28 x Ø 0,15 mm) | 2 | |
| E12551 | Female cordset | 5 m PUR-Cable; DEUTSCH connector Connector | 2 x 0,50 mm² (28 x Ø 0,15 mm) | 2 | |
| E18026 | Female cordset | 4 m PUR-Cable; 1/2" Connector | 5 x 0,34 mm² (19 x Ø 0,16 mm) | 5 | |
| E18027 | Female cordset | 4 m PUR-Cable; 1/2" Connector | 5 x 0,34 mm² (19 x Ø 0,16 mm) | 5 | |
| E18200 | Female cordset | 2 m TPE-S-Cable; 1/2" Connector | 3 x 0,34 mm² | 3 | |
| E18201 | Female cordset | 5 m TPE-S-Cable; 1/2" Connector | 3 x 0,34 mm² | 3 | |
| E18202 | Female cordset | 10 m TPE-S-Cable; 1/2" Connector | 3 x 0,34 mm² | 3 | |
| E18203 | Female cordset | 2 m TPE-S-Cable; 1/2" Connector | 3 x 0,34 mm² | 3 | |
| E18204 | Female cordset | 5 m TPE-S-Cable; 1/2" Connector | 3 x 0,34 mm² | 3 | |
| E18205 | Female cordset | 10 m TPE-S-Cable; 1/2" Connector | 3 x 0,34 mm² | 3 | |
| E18242 | Female cordset | 10 m PVC-Cable; 1/2" Connector | 5 x 0,34 mm² (19 x Ø 0,16 mm) | 5 | |
| E18243 | Female cordset | 9 m PUR-Cable; 1/2" Connector | 5 x 0,34 mm² (19 x Ø 0,16 mm) | 5 | |
| EVC001 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC002 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC003 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC004 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC005 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC006 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC007 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 2 x LED yellow; Power: 1 x LED green | 4 |
| EVC008 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 2 x LED yellow; Power: 1 x LED green | 4 |
| EVC009 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 2 x LED yellow; Power: 1 x LED green | 4 |
| EVC04A | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC05A | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC06A | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC070 | Female cordset | 2 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC071 | Female cordset | 5 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC072 | Female cordset | 10 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC073 | Female cordset | 2 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC074 | Female cordset | 5 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC075 | Female cordset | 10 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC082 | Female cordset | 15 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC083 | Female cordset | 20 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC084 | Female cordset | 25 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC085 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC086 | Female cordset | 15 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC087 | Female cordset | 20 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC088 | Female cordset | 25 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC089 | Female cordset | 6 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC091 | Female cordset | 25 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 2 x LED yellow; Power: 1 x LED green | 4 |
| EVC129 | Female cordset | 15 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 2 x LED yellow; Power: 1 x LED green | 4 |
| EVC141 | Female cordset | 2 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC142 | Female cordset | 5 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC143 | Female cordset | 10 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC144 | Female cordset | 2 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC145 | Female cordset | 5 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC146 | Female cordset | 10 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC147 | Female cordset | 2 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | Switching status: 1 x LED yellow; Power: 1 x LED green | 3 |
| EVC148 | Female cordset | 5 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | Switching status: 1 x LED yellow; Power: 1 x LED green | 3 |
| EVC149 | Female cordset | 10 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | Switching status: 1 x LED yellow; Power: 1 x LED green | 3 |
| EVC14A | Female cordset | 25 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC150 | Female cordset | 2 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC151 | Female cordset | 5 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC152 | Female cordset | 10 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC153 | Female cordset | 2 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC154 | Female cordset | 5 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC155 | Female cordset | 10 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC158 | Female cordset | 1.1 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC15A | Female cordset | 40 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC161 | Female cordset | 2 m PUR-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) | 2 | |
| EVC162 | Female cordset | 5 m PUR-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) | 2 | |
| EVC163 | Female cordset | 10 m PUR-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) | 2 | |
| EVC164 | Female cordset | 2 m PUR-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) | 2 | |
| EVC165 | Female cordset | 5 m PUR-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) | 2 | |
| EVC166 | Female cordset | 10 m PUR-Cable; M12 Connector | 2 x 0,34 mm² (42 x Ø 0,1 mm) | 2 | |
| EVC186 | Female cordset | 2.5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC196 | Female cordset | 1 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC197 | Female cordset | 15 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC198 | Female cordset | 20 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC199 | Female cordset | 25 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC207 | Female cordset | 5.8 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC29A | Female cordset | 50 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC30A | Female cordset | 80 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC348 | Female cordset | 35 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC349 | Female cordset | 3 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC387 | Female cordset | 15 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC388 | Female cordset | 20 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC401 | Female cordset | 5 m PUR-Cable; M12 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC406 | Female cordset | 3 m PUR-Cable; M8 Connector | 4 x 0,25 mm² (32 x Ø 0,1 mm) | 4 | |
| EVC423 | Female cordset | 15 m PUR-Cable; M12 Connector | 5 x 0,34 mm² (42 x Ø 0,1 mm) | 5 | |
| EVC471 | Female cordset | 1 m PUR-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| EVC490 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC491 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² | 4 | |
| EVC497 | Female cordset | 3 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC501 | Female cordset | 20 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC502 | Female cordset | 45 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC526 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC527 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC528 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC529 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC530 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC531 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC532 | Female cordset | 2 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC533 | Female cordset | 5 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC534 | Female cordset | 10 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC535 | Female cordset | 2 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC536 | Female cordset | 5 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC537 | Female cordset | 10 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC538 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC539 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC540 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC541 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC542 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC543 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC544 | Female cordset | 2 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC545 | Female cordset | 5 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC546 | Female cordset | 10 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC547 | Female cordset | 2 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC548 | Female cordset | 5 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC549 | Female cordset | 10 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC551 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC561 | Female cordset | 30 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC562 | Female cordset | 50 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC563 | Female cordset | 15 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC591 | Female cordset | 60 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC597 | Female cordset | 20 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC629 | Female cordset | 20 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVC633 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC643 | Female cordset | 14 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC644 | Female cordset | 2 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 4 x LED yellow; Power: 2 x LED green | 4 |
| EVC645 | Female cordset | 5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 4 x LED yellow; Power: 2 x LED green | 4 |
| EVC646 | Female cordset | 10 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | Switching status: 4 x LED yellow; Power: 2 x LED green | 4 |
| EVC651 | Female cordset | 15 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC698 | Female cordset | 15 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC759 | Female cordset | 40 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC767 | Female cordset | 25 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC818 | Female cordset | 6 m PUR-Cable; M8 Connector | 3 x 0,25 mm² (32 x Ø 0,1 mm) | 3 | |
| EVC837 | Female cordset | 4 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC838 | Female cordset | 6 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVC968 | Female cordset | 7.5 m PUR-Cable; M12 Connector | 4 x 0,34 mm² (42 x Ø 0,1 mm) | 4 | |
| EVCA10 | Female cordset | 30 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| EVCA11 | Female cordset | 50 m PUR-Cable; M12 Connector | 5 x 0,25 mm² (32 x Ø 0,1 mm) | 5 | |
| L31000 | Female cordset | 2 m PVC-Cable; 7/8" Connector | 3 x 1,5 mm² | 3 |
