Safe door switches
AS-i door switches with guard locking have the function to keep moving protective equipment such as protective grating, protective guards and other covers closed as long as a dangerous state is present. They are operated in safe AS-i systems (Safety at Work) and function as electromagnetic interlocks with guard locking.
In combination with a guard and the machine control system this safety component prevents the safety guard from being opened while there is potential of exposure to a mechanical hazard. For the control system this means that switch-on commands which cause hazardous situations must become active only when the safety guard is in a protective position and the guard locking in locked position. The locked position of the guard locking must be released only when the hazardous situation is no longer present.
- Power-to-lock and power-to-unlock versions available
- Rotatable actuating head made of metal
- Mechanical release on the front
- Space-saving design
- Suited for applications up to Performance Level PL d
MPN | Product designation | Number of digital inputs | Sensor supply of the inputs | Number of digital outputs | Sensor supply |
---|---|---|---|---|---|
AC901S | Safety switch with guard locking | ||||
AC902S | Safety switch with guard locking | ||||
AC903S | Safety switch with guard locking | ||||
AC904S | Safety switch with guard locking | ||||
E7901S | Bolt for safety guards | ||||
E7902S | Bolt for safety guards | ||||
E7903S | Actuator S standard straight | ||||
E7904S | Actuator S standard bent | ||||
E7905S | Hinged actuator left / right | ||||
E7906S | Hinged actuator top / bottom |
SKU | Description | List price | - |
---|---|---|---|
IFM-050050005 | Industrial Communication - Safety Network (AS-i safety at work) - Gateways with fail-safe PLC | $0.01 | |
IFM-050050010 | Industrial Communication - Safety Network (AS-i safety at work) - Safety monitors | $0.01 | |
IFM-050050020 | Industrial Communication - Safety Network (AS-i safety at work) - Safe input/output modules | $0.01 | |
IFM-050050030 | Industrial Communication - Safety Network (AS-i safety at work) - E-stop devices | $0.01 | |
IFM-050050060 | Industrial Communication - Safety Network (AS-i safety at work) - Rope pull emergency stop switches | $0.01 | |
IFM-050050070 | Industrial Communication - Safety Network (AS-i safety at work) - PCB solutions | $0.01 |
