Headline
PC-Series
Power Supplies
Features & Benefits
Features:
- Single or dual power supply
- Rugged plastic housing
- Wall, panel, or outlet mounting styles
- 24 Vdc and 12 Vdc, depending on model
Additional Notes
| Specs | Value |
|---|---|
| Input Power | 85–264 Vac, 45–65 Hz |
| Output Voltage/Current | 12 Vdc ±1%, /1A (Regulated) |
| Output Noise | < 10 mV p-p |
| Screw Terminal Wire | 12–24 AWG |
| MTBF | 500,000 hours |
| Operating Temperature | -13˚ to 158˚ F (-25˚ to 70˚ C) |
| Regulatory Approvals | UL, UL/C (Canada) listed, CE |
| Environmental | IP20, non-condensing |
Dimensional drawings
