iMAG 4700 Industrial Flanged Magmeters

iMAG 4700

Industrial Flanged Magmeters

The iMAG-Series is the most economical flanged electromagnetic flowmeter on the market. With electrodes designed to discourage fouling, it is available in 2" to 12" pipe in municipal or industrial water, waste and reclaimed water, pump stations, and packaged plant applications. Minimal straight pipe requirements allow iMAG-Series meters to be used in piping configurations where there is little space between the meter and an elbow.

Key Features

Power & Installation

• Easy Setup
• External AC or DC power versions
• Battery backup capability
• Minimal straight pipe requirements

Monitoring & Output

• Meter mounted rate/total indicator
• Pulse and 4-20mA output standard
• Optional outputs:
  • HART/4-20mA
  • Modbus
  • Digital
• Optional datalogger

Applications

• Water & wastewater treatment
• Municipalities
• Pump skids
• Pump stations
• Packaged plants
• Filtration systems
• Reclaimed water
• Hydraulic fracturing

Certifications

• NSF-61 approved
• IP68 rated
