Pictures may not be actual SKU
Product details
Spot an error? Let us know!
Headline
Accessories/Miscellaneous - O-rings and sealing rings
O-rings and sealing rings are used for reliable sealing of process sensors installed in pipes or vessels. With natural rubber O-rings, the units can even be sealed to very high pressures. When fitting the O-ring, pushing it into place creates the initial seal. The combination of initial seal and system pressure being applied results in the final sealing pressure.
Features & Benefits
- Reliable axial and radial sealing
- Sealed even at very high system pressure
Additional Notes
| MPN | Product designation | Inside diameter | Outer diameter | Material | Pack quantity |
|---|---|---|---|---|---|
| E12451 | Process connection sealing | O-ring: FKM; supporting ring: PTFE | 1 pcs. | ||
| E30053 | O-ring | 24 mm | 28 mm | FKM | 5 pcs. |
| E30054 | O-ring | 24 mm | 28 mm | EPDM | 5 pcs. |
| E30111 | Gasket | 12 mm | 21 mm | NBR; steel | 50 pcs. |
| E30123 | O-ring | 24 mm | 28 mm | FKM | 1 pcs. |
| E30124 | Gasket | 25.9 mm | 29 mm | PEEK FDA compliant | 1 pcs. |
| E30145 | Gasket | 11.6 mm | 16.5 mm | FKM | 10 pcs. |
| E30146 | Gasket | 29.7 mm | 35.7 mm | FKM | 10 pcs. |
| E30147 | O-ring | 31 mm | 34 mm | FKM | 10 pcs. |
| E30437 | O-ring | 26 mm | 32 mm | FKM | 1 pcs. |
| E30438 | O-ring | 26 mm | 32 mm | EPDM | 1 pcs. |
| E30442 | Gasket | 11.6 mm | 16.5 mm | EPDM | 10 pcs. |
| E30451 | Gasket | 18.5 mm | 23.9 mm | EPDM | 10 pcs. |
| E30459 | Gasket | 15.4 mm | 18.8 mm | PEEK, FDA compliant | 1 pcs. |
| E30492 | Gasket | 18.5 mm | 23.9 mm | FKM | 5 pcs. |
| E40239 | O-ring | 47.22 mm | 54.28 mm | FKM | 2 pcs. |
| E40243 | Gasket | 13.5 mm | 16 mm | NBR fibre-reinforced | 10 pcs. |
| E40244 | Gasket | 12 mm | 18.5 mm | Centellen | 10 pcs. |
| E40245 | Gasket | 17 mm | 24 mm | Centellen | 10 pcs. |
| E40246 | Gasket | 23.5 mm | 30 mm | Centellen | 10 pcs. |
| E40247 | Gasket | 29.5 mm | 38 mm | Centellen | 10 pcs. |
| E40248 | Gasket | 43 mm | 55 mm | NBR fibre-reinforced | 10 pcs. |
| E40453 | O-ring | 47.22 mm | 54.28 mm | EPDM | 2 pcs. |
| E43323 | Gasket | sealing ring on sensor side: EPDM; sealing ring on process side: PEEK in contact with the medium | 1 pcs. | ||
| E43326 | O-ring | 18.72 mm | 23.96 mm | FKM | 5 pcs. |
| E43338 | O-ring | 6.5 mm | 9.5 mm | EPDM | 5 pcs. |
| E43339 | O-ring | 6.5 mm | 9.5 mm | FKM | 1 pcs. |
| E43376 | Gasket | 21.3 mm | 26.5 mm | NBR fibre-reinforced | 5 pcs. |
| E43911 | Gasket | sealing ring on sensor side: FKM; sealing ring on process side: PEEK in contact with the medium | 1 pcs. |
