Features & Benefits
- Actuation possible from different directions
- Meets the interface description CB24I from ZVEI
- Can be connected in series
- Conceal behind stainless steel for enhanced tamper prevention
- Meets highest safety levels to ISO 13849-1 and SILCL 3 to IEC 62061
Additional Notes
| MPN | Sensing range | Design | Output function | Output | Dimensions |
|---|---|---|---|---|---|
| MN200S | 5 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 36 x 13 x 26 mm |
| MN201S | 5 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 36 x 13 x 26 mm |
| MN202S | 5 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 36 x 13 x 26 mm |
| MN203S | 5 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 36 x 13 x 26 mm |
| MN204S | 5 mm non-flush mountable | coded target | 2 x normally open, 1 x normally closed; (potential-free) | DC | 36 x 13 x 26 mm |
| MN205S | 5 mm non-flush mountable | coded target | 2 x normally open, 1 x normally closed; (potential-free) | DC | 36 x 13 x 26 mm |
| MN206S | 5 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 36 x 13 x 26 mm |
| MN207S | 5 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 36 x 13 x 26 mm |
| MN500S | 8 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm |
| MN501S | 8 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm |
| MN502S | 8 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm |
| MN503S | 8 mm non-flush mountable | coded target | 2 x normally open; (potential-free) | DC | 88 x 13.1 x 25 mm |
| MN504S | 8 mm non-flush mountable | coded target | 2 x normally open, 1 x normally closed; (potential-free) | DC | 88 x 13.1 x 25 mm |
| MN505S | 8 mm non-flush mountable | coded target | 2 x normally open, 1 x normally closed; (potential-free) | DC | 88 x 13.1 x 25 mm |
| MN508S | 8 mm non-flush mountable | coded target | 2 x normally open, 1 x normally closed; (potential-free) | DC | 88 x 13.1 x 25 mm |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-030070020 | Safety Sensors - Coded safety sensors - RFID coded | $0.01 |
