Pictures may not be actual SKU
Product details
Spot an error? Let us know!
Headline
Signalling and display systems - mini-displays for limit value monitoring
The mini-displays are used to display, evaluate and convert signals. The compact device is installed in the signal path between a sensor and the controller. This enables a user-friendly display of the measured values on site. In addition to the display function, the display has a switching function for limit value monitoring.
The display can be switched to an alternating indication of red and green. Critical process statuses or operating faults can thus be reliably signalled.
Additionally, the signals can be converted into digital IO-Link signals.
Features & Benefits
- For the reliable limit value monitoring of analog sensors
- Clearly visible LED display with red/green color change
- User-friendly communication and parameterization via IO-Link
- Compact housing with high protection rating
- Reliable signal conversion of analog measured values in IO-Link
Additional Notes
| MPN | Product designation | Operating voltage DC | Electrical design | Output function | Connection |
|---|---|---|---|---|---|
| DP2200 | Measured value and limit value display / converter 4…20 mA – IO-Link | 18...30 V | normally open / closed; (configurable); analog | M12 Connector |
Alternate configurations
| SKU | Description | List price | - |
|---|---|---|---|
| IFM-015050010 | Motion Control Sensors - Signal conversion systems - Pulse stretching | $0.01 | |
| IFM-015050020 | Motion Control Sensors - Signal conversion systems - Pulse dividers | $0.01 | |
| IFM-015050030 | Motion Control Sensors - Signal conversion systems - Frequency-to-current converters | $0.01 | |
| IFM-015050040 | Motion Control Sensors - Signal conversion systems - Switch-on and switch-off delay | $0.01 | |
| IFM-015050050 | Motion Control Sensors - Signal conversion systems - PNP/NPN inverter modules | $0.01 | |
| IFM-015050070 | Motion Control Sensors - Signal conversion systems - IO-Link converter | $0.01 |
