EchoPod UG01 & UG03 Reflective Ultrasonic Multi-Function Liquid Level Sensor Transmitter

The general purpose reflective ultrasonic multi-function level transmitter provides continuous level measurement up to 9.8' (3m) with a 4-20 mA analog signal output and four relays, and is configured via our WebCal software. The non-contact liquid level sensor features our proprietary Reflective Technology that delivers reliable level measurement in condensing environments. Each relay can be configured for alarm, automatic fill or empty functions. Select this sensor for small tanks with non-foaming and mildly vaporous media such as chemicals, water, wastewater and oil. Typical applications include day tank, IBC or drum, cooling tower, skid or machine, process tank and waste sumps.

Key Features

Measurement & Detection

• Offered in 1.5m (4.9') and 3m (9.8') measurement ranges
• Narrow 2" (5cm) beam width for applications with limited space
• Short 1.5" (3.8cm) dead band maximizes tank filling capacity

Construction & Protection

• Corrosion resistant PVDF transducer
• Compact PP enclosure
• Automatic temperature compensation from -40° to 80° C

Control & Programming

• Fail-safe diagnostics with selectable relay and signal outputs
• Four programmable relays with embedded level control logic:
  • 1 pump or valve with 3 alarms
  • 2 pumps lead-lag with 2 alarms
  • 2 pumps duplexing with 2 alarms
  • 4 independent switch point alarms
