LR46-5321-04-00 | 26 GHz. - 10” (246mm) Parabola - 4” ANSI Gimbaled Flange - 316L

EchoPro LR46 Radar Solids Level Sensor Transmitter

The intrinsically safe 26 GHz. pulse radar transmitter provides continuous level measurement up to 229.7' (70m) with a 4-20 mA analog and HART digital signal output, and is configured via its integral push button display module or HART communicator. The non-contact solids level sensor is intended for dry solid media including aggregates, grains, pellets, powders and building materials. Select this sensor for the most difficult process conditions with significant to extreme dust, and installation with an adjustable gimbal flange. For ease of installation, the parabolic antenna can be unclamped, inserted through the base of a riser, and reattached to the sensor. Typical applications include silos.

Key Features

Advanced Signal Processing

• Parabolic antenna delivers high power RF signal strength
• Recognition, storage and rejection of false echo signal returns
• Fail-safe diagnostics with selectable signal fail-safe outputs

User Interface & Configuration

• Configuration via push button display or HART communicator
• LCD displays level in feet or meters with percent of span bar
• Optional display mode indicates the echo signal return curve

Rugged Construction

• Gimbal flange for easy positioning with the angle of repose
• Rugged 316L stainless steel antenna and process mount
• IP67 stainless enclosure with polycarbonate display window
