EchoPro LR26 Radar Liquid Level Sensor Transmitter
The intrinsically safe 6.3 GHz. pulse radar transmitter provides continuous level measurement up to 114.8' (35m) with a 4-20 mA analog and HART digital signal output, and is configured via its integral push button display module or HART communicator. The non-contact liquid level sensor is intended for chemical and petroleum storage or process applications in above grade metal or reinforced concrete tanks or below grade tanks of any material. Select this sensor for harsh process conditions with corrosive or low dielectric media, heavy surface foam or agitation, higher pressure, steam, condensation or vapor, and installation in a flange fitting. Due to the wider beam angle, special attention should be given to ensure that the sensor is located with unobstructed measurement space. Typical applications include process tanks.
Key Features
Advanced Sensing & Display
- 6.3 GHz pulse radar unaffected by foam and agitation
- LCD display shows level in feet/meters with span bar
- Optional echo signal return curve display mode
- Auto-temperature compensation for accuracy
Robust Construction
- 316L antenna with PTFE inner shield for corrosive media
- IP67 stainless enclosure
- Polycarbonate display window
- 12" (30cm) dead band for full tank utilization
Intelligent Controls
- Configuration via push button display or HART communicator
- Fail-safe diagnostics with selectable outputs
- Recognition, storage and rejection of false echo signals
Technical Specifications
| Parameter | Specification |
|---|---|
| Frequency | 6.3 GHz |
| Dead Band | 12" (30cm) |
| Protection Rating | IP67 |
| Display Type | LCD |
| Configuration | Push button/HART |
| Housing Material | Stainless steel |
| Window Material | Polycarbonate |
| Antenna Material | 316L with PTFE shield |
