EchoPulse LR25 Radar Liquid Level Sensor Transmitter
The general purpose 6.3 GHz. pulse radar level transmitter provides continuous level measurement up to 114.8' (35m) with a 4-20 mA signal output, and is configured via its integral push button display module. The non-contact liquid level sensor is intended for chemical and petroleum storage or process applications in above grade metal or reinforced concrete tanks or below grade tanks of any material. Select this sensor for harsh process conditions with corrosive or low dielectric media, heavy surface foam or agitation, higher pressure, steam, condensation or vapor, and installation in a flange fitting. Due to the wider beam angle, special attention should be given to ensure that the sensor is located with unobstructed measurement space. Typical applications include process tanks.
Key Features
Advanced Sensing & Display
- 6.3 GHz pulse radar unaffected by foam and agitation
- LCD displays level in feet/meters with percent span bar
- Optional echo signal return curve display mode
- 12" (30cm) dead band for full tank utilization
Robust Construction
- 316L antenna with PTFE inner shield for corrosive media
- Rugged IP67 aluminum enclosure
- Polycarbonate window protection
Intelligent Operation
- Simple configuration via push button display module
- Fail-safe diagnostics with selectable outputs
- Recognition, storage and rejection of false echo signals
Technical Specifications
| Parameter | Value |
|---|---|
| Frequency | 6.3 GHz |
| Dead Band | 12" (30cm) |
| Protection Rating | IP67 |
| Antenna Material | 316L |
| Shield Material | PTFE |
| Enclosure | Aluminum |
| Window | Polycarbonate |
