LV42-7201 | PP - 20' Cable

Switch-Tek LV42 Sump Float Level Switch

The general purpose sump float level switch provides reliable liquid level detection and is designed for the automation of pumps, filling or emptying of tanks, wells and reservoirs. The switch body is free of any irregularities and consists of a double airtight chamber with a high-pressure melted polypropylene seal for use in wastewater applications.

Features:

• Mercury-free counter-weighted double chambered float
• Submersible PP body and PVC cable for corrosive liquids
• Dry contact selectable NO or NC state via wiring selection
• Compatible with counter weight and cable hanger installations

Benefits:

• Ideal for use in sewage water applications
• Float can wire directly to PLC/ SCADA or controller
• Counter-weighted float minimizes the effects of relay chatter
• Double-airtight chamber helps protect from debris infiltration
