RB-1000S4-GPM1 | F-1000-RB 600-6000 GPM 10"IPS S40 PVC

Pictures may not be actual SKU

RB-1000S4-GPM1 | F-1000-RB 600-6000 GPM 10"IPS S40 PVC

Name: RB-1000S4-GPM1 | F-1000-RB 600-6000 GPM 10"IPS S40 PVC
Brand: Blue-White
SKU: BWI-42100300
Price: 530.17 USD
Availability: InStock

BWI | Blue-White

F-1000 | F-1000 Digital Paddlewheel Flow Meters

F-1000-RB | Flow Rate - Paddlewheel Flowmeter

BWI-42100300

Description

Blue-White's RB-1000S4-GPM1 Paddlewheel Flowmeter F-1000-RB 600-6000 GPM 10"IPS S40 PVC. Item # 42100-300 (EF)

Configuration

Base Model

Model

RB | Flow Rate

Size

1000 | 10" Pipe

Connections

Type

S4 | Saddle Mount - Schedule 40

Configuration

Units

GPM | Gallons per Minute

Flow Range

1 | Range 1 (see pipe fitting detail)

Options

_ | Standard

Available to Order

Ships from PA - FL - OH - TX - OR

Typically ships within [ 12 ] days

24/7 Sales & Support 484-544-0506

$530.17 Configured Price

Quantity:

− +

Overview
Tech Specs
Support Docs
Dimensions
SKU List

Headline

F-1000RB DIGITAL PADDLEWHEEL FLOWMETER (RB = Rate Only)

Easy to read 6 digit LCD, up to 4 decimal positions.

Flow Range: 0.4 - 8000 GPM (1 - 27000 LPM) Pipe Sizes: ⅜", up to 12" Sensor mounted on pipe fitting. Battery operated.

Features & Benefits

Key Features

Display & Interface

Easy to read 6 digit LCD display
- Up to 4 decimal positions
- Display update rate: 1.5 seconds
- Total update rate: 0.5 seconds
Total Reset function can be disabled
Factory calibrated with no programming required

Installation & Power

Flexible mounting options
- Vertical or horizontal installation
- Standard models include pipe fitting
Battery operated (2 AAA batteries included)

Environmental Protection

NEMA 4X weather resistant enclosure
LCD display not recommended for direct sunlight exposure

Technical Specifications

Parameter	Value
Display Type	6 digit LCD
Decimal Positions	Up to 4
Rate Update Time	1.5 seconds
Total Update Time	0.5 seconds
Power Source	2 AAA batteries
Enclosure Rating	NEMA 4X

Manual

F1000 Operating Manual

Model Codes

F1000 Model Number Matrix

Datasheet

F1000 Flow Meter Tech Datasheet

Performance Charts

F1000 Temp vs Pressure PVDF Chart F1000 Temp vs Pressure PVC Chart

Dimensional drawings

Drawing A

Alternate configurations

SKU	Description	List price	-
BWI-42100113	RB-100AT-GPM1 \| F-1000-RB 6-60 GPM 1.0" IPS SLIP PVC TEE	$530.17	BWI-42100113 Detail
BWI-42100116	RB-100AT-LPM1 \| F-1000-RB 25-250 LPM 1" IPS SLIP PVC TEE	$530.17	BWI-42100116 Detail
BWI-42100301	RB-1000S8-GPM1 \| F-1000-RB 600-6000 GPM 10"IPS S80 PVC	$530.17	BWI-42100301 Detail
BWI-42100304	RB-1000S8-LPM1 \| F-1000-RB 2500-25000 LPM 10"IPS S80 PVC	$530.17	BWI-42100304 Detail
BWI-42100305	RB-1000S4-LPM1 \| F-1000-RB 2500-25000 LPM 10"IPS S40 PVC	$530.17	BWI-42100305 Detail
BWI-42100308	RB-1000S8-M3H1 \| F-1000-RB 150-1500 M3H 10" IPS S80 PVC	$530.17	BWI-42100308 Detail
BWI-42100314	RB-1000S4-M3H1 \| F-1000-RB 135-1350 M3H 10"IPS S40 PVC	$530.17	BWI-42100314 Detail
BWI-42100541	RB-100MI-GPM1 \| F-1000-RB 5-50 GPM 1.0" MPT	$530.17	BWI-42100541 Detail
BWI-42100551	RB-100MI-LPM1 \| F-1000-RB 20-200 LPM 1" MPT	$530.17	BWI-42100551 Detail
BWI-42100555	RB-100MI-M3H1 \| F-1000-RB 1.2-12 M3H 1.0" MPT	$530.17	BWI-42100555 Detail
BWI-42100559	RB-100MI-GPH1 \| F-1000-RB 300-3000 GPH 1.0" MPT	$530.17	BWI-42100559 Detail
BWI-42100595	RB-100MB-LPM2 \| F-1000-RB 7-70 LPM 1" BSPT PP	$530.61	BWI-42100595 Detail
BWI-42100599	RB-100MB-LPM1 \| F-1000-RB 20-200 LPM 1"BSPT PP	$530.17	BWI-42100599 Detail
BWI-42120000	RB-1200S8-GPM1 \| F-1000-RB 800-8000 GPM 12"IPS S80 PVC	$530.17	BWI-42120000 Detail
BWI-42120001	RB-1200S4-GPM1 \| F-1000-RB 800-8000 GPM 12"IPS S40 PVC	$530.17	BWI-42120001 Detail
