Headline
CHEM-FEED® PLASTIC SKID
Compatible with: FLEX-PRO® and CHEM-PRO® metering pumps Mounting Positions: Floor or Wall
Features & Benefits
CHEM-FEED Engineered Skid Systems
System Overview
- Designed using solid modeling tools for superior piping installation
- Easy component maintenance and servicing
- Lightweight construction for wall or floor mounting
- Factory built and tested
- Custom engineered universal mounting blocks
Standard Components
- Pressure Relief Valve
- Protects from over-pressurization
- Setting range: 10-150 psi
- Maximum system pressure: 150 psi
- Check Valve
- Protects from back-flow during maintenance
- Flow Indicator
- Visual indication of chemical movement
- Inlet Y Strainer
- Recommended for Diaphragm Pump systems
Optional Components
- Calibration Cylinder
- Confirms pump output under system conditions
- Available volumes: 1.6 GPH to 64 GPH
- Pulsation Dampener
- Protects system components from pulsation
- Recommended for diaphragm pump systems
- Pressure Gauge with Guard
- Isolates and protects system pressure gauge
- Available ranges: 0-30 psi, 0-100 psi, or 0-200 psi
- S6A Chemical Flowmeter
- Provides 4-20mA and pulse output data
- SCADA compatible
- Verifies chemical feed
- See S6A data sheet for details
Technical Specifications
| Component | Range/Rating |
|---|---|
| Pressure Relief | 10-150 psi |
| Maximum System Pressure | 150 psi |
| Calibration Cylinder | 1.6-64 GPH |
| Pressure Gauge Options | 0-30/100/200 psi |
| Flowmeter Output | 4-20mA |
